- Remote control Valve is responsible for controlling the flow of sand and air to the blasting nozzle
- Remote control Valve for sand / shot blasting machine.
- An inlet connection point to attach the control box's air supply line.
- The remote control Valve is a switch to turn on and off the airflow to the air motor positioned at the valve in the abrasive blasting machine.
- A hose to connect the air motor at the valve and control box. In order for the valve to be remotely actuated in either direction, two lines of hose are needed.
- A switch that directs the flow of air through one of the hoses.
- A lubricator, regulator, and filter. The lubricator lubricates the motor at the valve while the filter cleans the air supply to the motor.
- The regulator, which controls air pressure, is movable.
Leading Supplier & Exporter
Trustseal Verified
ISO Certified
Manufacturer
The Remote Control Valve system is used by a single abrasive blasting machine operator for starting up and shutting down the Sand Blasting machine. The remote control valve system comprises a remote control valve and remote control DMS (dead man switch), which are connected by a twin tube.
The control handle often referred to as a dead man switch, is the trigger for the Remote Control Valves System. When the operator releases the RC handle, sandblasting machine deactivates, stopping air and abrasive flow through the Sand blasting nozzle.
The Remote Controls Valve operates pneumatically. If the operator is not pressing the dead man handle, one stream of air travels down the outbound side of the twin line and escapes through an opening located under the lever. The usually closed inlet valve remains closed, and the usually open outlet valve remains open.
When the dead man handle lever is pressed, the opening is sealed, and air in the outbound line returns through the inbound line to open the inlet valve and close the outlet valve. This action pressurizes the Sand Blasting machines and begins the blasting process. Freeing the handle puts the machine in exhaust mode, which closes the inlet valve, and opens the outlet valve to depressurize the sand blasting machine and stop the blasting.
Pneumatic remote controls work great in blasting operations with blast hose lengths less than 100 ft.
Remote Control Valve Model RM 1 Specification
| Length | 27 cm |
| Width | 10 cm |
| Weight | 2670 g |
| Thickness | 0.8 m |
Remote Control Valve Model RM 2 Specification
| Length | 27 cm |
| Width | 10 cm |
| Weight | 4409 g |
| Thickness | 0.8 m |
Remote Control Valve Manufacturer
Airo Shot Blaster Manufacturer of Remote Control Valve in India. we are also manufacturer, supplier and Exporter of sand blasting cabinet, shot blasting machine,sand blasting nozzle, grit blasting machine, pressure blasting cabinet,pressure Shot Blasting Cabinetat low price for sale.
