Tell us the component type, coating use, and expected production need.
System Overview
Spray Booth
8Lakh - 1CR
Spray Booth System
Material to be painted
Steel, Aluminum, Iron, Wood, Plastic
Voltage
440V
Phase
Three
Air Flow
5000 CFM
Direct consultation for system selection
Brochure and commercial support
Application-based product guidance
Technical Details
Technical specifications and additional information for Spray Booth.
Technical Specifications
| Material to be painted | Steel, Aluminum, Iron, Wood, Plastic |
|---|---|
| Voltage | 440V |
| Phase | Three |
| Air Flow | 5000 CFM |
| Speed | 900 RPM |
| Motor | Axial Flow |
| Features | End Draft / Side Draft |
Additional Information
| Color | As per client requirement |
|---|---|
| Country | India |
| Brand | Airo Shot Blast |
| Delivery Time | 20-25 Days |
| Minimum Order Quantity | 1 |
Applications and Suitability
Application fit and key selection factors before enquiry.
- Spray booths are used for painting applications.
- Long operational life
- Corrosion-resistance
- Rugged design
- The spray environment presents a variety of unique obstacles to manufacturers of industrial products.
- An industrial spray booth must take into account the specific production requirements of a manufacturer's specialized finishing procedures, from spray coating golf balls to painting wood furniture.
- There isn't a single industrial finishing method that works for everyone.
Best for
Spray Booth System requirement
Typical use
Process fit and operating requirement review
Next step
Quote, brochure, or suitability discussion
Why Buyers Choose This System
Cleaner coating environment
Choose a spray booth system that supports cleaner finishing work and practical production use.
Better finishing control
Compare system suitability according to part size, process flow, and coating requirement.
Setup clarity
Review system layout, working arrangement, and support options before moving to quotation.
Selection support
Our team assists with brochure review, technical discussion, and buying clarity.
How We Help You Finalize
Step-by-step guidance before pricing and final product discussion.
We help match the suitable spray booth system to your requirement.
Check technical details, layout fit, and recommendation support before finalizing.
Request the latest quote, brochure, and support through one clear enquiry path.
Product Overview
Thermal Spray Booth
These spray booths can be cracked from the front or closed as per job coating operation and process design. The ergonomically created front part is very effective for the operator to perform the coating process and for the pull of over-sprayed material & fumes.
To perform the thermal spray gunprocess on small portions for group or mass levels of coating, and we full variety of spray booths designed to meet customer’s demands.
SPRAY BOOTH Specification
| Specification | PB 700 eco plus | PB 700 Eco |
| Dimensions(Outside) | 7000 x 5350 x 3400 mm | 7000 x 5350 x 3400 mm |
| Dimensions (inside) | 6900 x 3900 x 2650 mm | 6900 x 3900 x 2650 mm |
| Dimensions( Main door ) |
3000 x 2600 mm | 3000 x 2600 mm |
| Dimensions (service door) | 650 x 1800 mm | 650 x 1800 mm |
| Flow Rate | 25000 m3/h | 25000 m3/h |
| Air velocity | 0.2 - 0.3 m/s | 0.2 - 0.3 m/s |
| Working temperature | 60-80°C | 60-80°C |
| Oil Consumption | 5-7 kg/car | 5-7 kg/car |
| Lighting intensity | 650 - 700 Lux | 650 - 700 Lux |
| Sound level | <80 dba | <80 dba |
| Power supply | 380V AC, 3 Phase, 50H | 380V AC, 3 Phase, 50Hz |
| Power | 20 HP | 13 HP |
Support and Delivery
System and application support
- System and process discussion
- Application-based selection guidance
- Brochure and quote support
- Commercial follow-up for buying clarity
Delivery and installation
- Delivery coordination guidance
- Installation discussion support
- Pre-dispatch system understanding
- Support on available options
System Video
Spray Booth video overview and product walkthrough.
Share Your Requirement
Send your requirement for faster system guidance and price response.
Tell us the process area, operating requirement, and expected output. Our team will respond with the relevant brochure, technical detail, and commercial guidance.
Product FAQs
What is Spray Booth used for?
Spray Booth is used for industrial surface preparation, cleaning, and finishing work where buyers need dependable spray booth system performance for production applications.
Which industries use Spray Booth?
Spray Booth is commonly considered by buyers in foundry, fabrication, steel processing, automotive, engineering, and project-based manufacturing depending on the type of component and production requirement.
How do I choose the right Spray Booth model?
The right model depends on component size, job handling method, required finish, output target, and plant usage. Airo Shot Blast helps buyers compare these points before finalizing Spray Booth.
Can I get the latest price for Spray Booth?
Yes. You can request the latest price for Spray Booth by sharing your requirement, preferred capacity, and production details so the team can guide you with a suitable commercial starting point.
Does Airo Shot Blast provide brochure and selection support for Spray Booth?
Airo Shot Blast can share brochure support, machine details, and requirement-based selection guidance for Spray Booth so buyers can compare models before moving to quotation.
What details should I send before enquiring about Spray Booth?
Before enquiring about Spray Booth, share your component type, material, production volume, finish expectation, and any preferred machine size or configuration for a more relevant response.
